Fingerboard Action at 12th Fret String Spacing Body Electronics Hardware

Wood	Maple
Construction	Bolt-on
Width at Nut	1.65″ (42mm)
Width at 12th Fret	2.07″ (52.5mm)
Thickness at 1st Fret	.77″ (19.5mm)
Thickness at 12th Fret	.90″ (23mm)
Wood	Phenowood
Radius	11.81″ (300mm)
Scale	24.8″ (630mm)
Nut	Teflon
Frets	Stainless Steel w/ Removeable Zero Fret
Treble	.059″ (1.5mm)
Bass	.078″ (2mm)
At Nut	1.38″ (35mm)
At Bridge	2.04″ (52mm)
Wood	Alder w/ Flame Maple Top
Weight	8.16lbs (3.7kg) (Approx.)
Type	Passive
Configuration	H-H
Pickups	Amber Hand Wound
Controls	Volume, Tone
Switch	5-way Blade
Bridge	Vigier Stoptail
Machine Heads	Vigier Locking
