Type: |
Solid Body |
|
Number of strings: |
7 |
|
|
|
Neck |
|
|
|
Type: |
Bolt-on featuring the 10/90 System (10% carbon, 90% wood) |
|
Wood: |
Maple naturally dried for 3 years |
|
Finish: |
Matte varnish |
|
Width of neck at nut: |
49 mm / 1.93" |
|
Width of neck at last fret: |
67 mm / 2.64" |
|
Depth of neck at first fret: |
20.5 mm / .807" |
|
Depth of neck at 12th fret: |
24 mm / .94" |
|
String spacing at nut: |
42 mm / 1.65" |
|
String spacing at bridge: |
64,8 mm / 2.55" |
|
Action as supplied at 12th fret, treble: |
1,5mm / 0.059" |
|
Action as supplied at 12th fret, bass: |
2.5 mm / .098" (Low B) |
|
Type of nut: |
Teflon nut + hardened zero fret technology |
|
|
|
Fingerboard |
|
|
|
Wood: |
Maple or rosewood |
|
Radius: |
300mm / 11.81" |
|
Type of frets: |
Stainless Steel frets, longer lasting
Medium size |
|
Number of frets: |
24 + zero fret |
|
Scale length: |
650mm / 25.6" |
|
Inlay: |
Dots |
|
|
|
Body |
|
|
|
Wood: |
Two center-joined pieces of solid, naturally aged alder. |
|
Top: |
Flamed maple |
|
Finish: |
Varnish dries for 5 weeks minimum |
|
|
|
Accessories |
|
|
|
Machine heads brand name: |
Vigier |
|
Type of machine heads: |
Over sized locking machine heads |
|
Bridge brand name: |
2017 non locking tremolo, pivoting on needles bearings More informations? |
|
End pin: |
Brass casing that inserts deep into the body and locks the strap button in place. |
|
Finish: |
Chrome only |
|
|
|
Electronic |
|
|
|
Pickup brand name: |
DiMarzio |
|
Type of pickup: |
HSH |
|
Pickup model: |
Blaze DP700, 701 and 702 |
|
Switch: |
5 way switch |
|
Electronic: |
- Volume
- Tone
- Kill Switch
Pickup selector :
1 Humbucker in neck position
2 Single-coil in neck & middle position
3 Single-coil in neck & bridge position
4 Single-coil in bridge & middle position
5 Humbucker in bridge position |
|
Shielding: |
Yes, with conductive painting linked to the ground |
|
|
|
Miscellaneous |
|
|
|
Weight: |
3.2Kg / 7.0lbs |
|
Delivered with gig bag/case: |
Yes, Vigier Hardcase |
|
Options: |
Download Vref here !
Vref lists and totals all of the options proposed by Vigier.
This software downloads very simply.
Please enter the code HTD-UK01 to get the retail prices in UK. |
|
Left handed version: |
no |
|
Strings: |
Ernie Ball, your choice of Strings Gauge |
|
Warranty: |
2 years |
|
Made in: |
France |
