מגבר אוזניות 4 ערוצים לאולפן
Inputs
|
|
Connector Type |
¼” TRS, balanced |
|
THD+N |
0.0025%, 1 kHz, unity gain |
|
Max Input Level |
+18 dBu, <0.5% THD+N, unity gain |
|
Input Impedance |
10 kΩ |
|
Frequency Response |
20 Hz - 20 kHz, ±0.5dB |
Monitor Outputs
|
|
Connector Type |
¼” TRS, asymmetrical, impedance-balanced |
|
THD+N |
0.0025%, 1 kHz, unity gain |
|
Max Output Level |
+18 dBu, <0.5% THD+N |
|
Output Impedance |
51Ω |
|
Frequency Response |
20 Hz - 20 kHz, ±0.5dB |
Headphone Outputs
|
|
Connector Type |
¼” TRS, stereo |
|
Max Output Power |
130 mW/Ch., <0.5% THD+N, 60Ω load |
|
Frequency Response |
20 Hz - 20 kHz, ±0.5 dB, 60Ω load |
|
Headphone Impedance Working Range |
32Ω - 600Ω |
Power
|
|
External Adapter Type |
+12 VDC, 1000 mA, center pin positive |
Physical
|
|
Dimensions |
1/3U rack-mount (with standard rack tray, not included) |
|
Height |
1.75” (44.45 mm) |
|
Depth |
5.5" (139.7 mm) |
|
Width |
5.5” (139.7 mm) |
|
Weight |
5 lbs (2.27 kg) |
As a commitment to constant improvement, PreSonus Audio Electronics, Inc., reserves the right to change any specification stated herein at any time, without notification.
|
|
|
