• 32 analog input channels over 4 × D-Sub 25 connectors with AC/DC coupling switch (TASCAM standard);

• 32 analog output channels over 4 × DC-coupled D-Sub 25 connectors (TASCAM standard);

• Dante™ audio over IP with primary port for audio transfer over long distances and a mirrored secondary port for redundancy;

• 2 × HDX ports (24-bit, 192kHz): up to 64 channels I/O for Pro Tools HD / HDX integration;

• Thunderbolt™ 3 port with custom macOS & Windows drivers for low latency performance in native DAW applications;

• Digital I/O: 64 channels of optical MADI, 8 channels of ADAT, and 2 channels over S/PDIF;

• Clocking I/O: 1 × word clock/loop sync input, 2 × word clock/loop sync outputs, 1 × 10М input;

• 1 × Dedicated stereo monitor output over ¼ TRS.

• Proprietary 64-bit AFC™ (Acoustically Focused Clocking) technology delivering spacious stereo image with distinct separation for an unrivalled level of detail;

• High-resolution A/D and D/A conversion ensuring artefact-free recordings and mastering-grade converter with 130dB headroom for critical listening without coloration or signal degradation.

• Collection of 37 Synergy Core effects modeled after classic and rare analog outboard gear;

• Synergy Core proprietary onboard platform powered by 6 × DSP & 2 × FPGA chips for real-time effects processing with imperceptible latency;

• Virtual patch-bay allowing execution of complicated input/output signal routing with a simple drag and drop;

• All digital ports can be used simultaneously for easy integration with multiple systems and different setups;

• 4 x onboard low-latency stereo mixers with 32 input channels each, with adjustable levels, panning and reverb settings – suitable for monitoring or summing;

• Customizable presets complete with signal routing, level adjustments, mixer settings and effects;

• Direct monitoring with effects, processed in real-time with imperceptible latency;

• Two 1.8″ IPS display screens for independent signal metering;

• Option to work without being connected to a computer (standalone operation);

• Wireless control of software features from a separate computer connected to the same network.

VEQ-4K BLACK (4-Band EQ / HPF / LPF)

VEQ-4K BROWN (4-Band EQ / HPF / LPF)

VEQ-4K ORANGE (4-Band EQ / HPF / LPF)

VEQ-4K PINK (4-Band EQ / HPF / LPF)

VEQ-HA32C (4-Band EQ / HPF / LPF)

VEQ-STU 900 (4-Band EQ / HPF / LPF)

NEU-W492 (4-Band EQ)

VMEQ-5 (3-Band Tube Mid-Range EQ )

BAE-1084 (3-Band EQ / HPF / LPF)

VEQ-STU 089 (3-Band EQ / HPF / LPF)

BAE-1023 (3-Band EQ / HPF)

VEQ-1A (2-Band Tube EQ)

VEQ-HLF (Tube 2-Band HPF / LPF)

VEQ-STU 169 (3-Band EQ / HPF)

NEU-PEV (3-Band EQ)

NEU-W495 (3-Band EQ)

Clear Q (Parametric EQ)

VCA160 (VCA Compressor / Limiter)

X903 (VCA Compressor / Limiter)

ALT-436C (Vari-Mu Tube Compressor Amplifier)

Tube 176 (Vari-Mu Tube Compressor / Limiter)

Stay-Levin (Vari-Mu Tube Compressor)

SMT-100A (Tube Leveling Amplifier / Limiter)

FET-A78 (FET Compress Stereo Peak Limiter)

FET-A76 (FET Compressor / Limiting Amplifier)

BAE 10DCF (Compressor / Limiter)

PowerEX (Expander)

PowerFFC (Feed-Forward Compressor)

PowerGate (Noise Gate)

BA-31 (Germanium Mic Preamp)

Gyraf Gyratec IX (Dual Tube Mic Preamp with HPF)

Marble White AutoWah (Auto-Wah Pedal)

Vari-Speed Tremolo (Tremolo)

Auraverb (Reverb)

Master De-Esser (De-Esser)

A-Tuner (Guitar Tuner)

● Power adapter

● Getting Started guide

Note: The device does not come with a Thunderbolt cable included

Device:

W: 48,3 cm (19 in); D: 27,9 cm (11 in); H: 4,4 cm (1,73 in); 3,4 kg (7,5 lbs)

Box:

W: 63,6 cm (25 in); D: 34 cm (13,4 in); H: 11 cm (4,3 in); 5 kg (11 lbs)
