Keyboard
|
61 keys (Piano-style)
|
|
Touch Response
|
2 sensitivity levels, Off
|
|
Sound Source
|
AHL(Dual-element)
|
|
Maximum Polyphony
|
48
|
|
Tones
|
700 built-in tones (10 user tones)
|
|
Layer/Split
|
Layer, Split(variable split point)
|
|
Digital Effects
|
Reverb: 10types
|
|
Chorus: 5 types (simultaneous use with DSP not supported.)
|
|
DSP: 100 preset, 100 user (simultaneous use with Chorus not supported.)
|
|
EQ(Equalizer): 5(Off, Soft, Bright, B.Boost, Powerful)
|
|
Auto Harmonize: 12
|
|
Arpeggiator: 150
|
|
Rhythms/Patterns
|
210 built-in rhythms (10 user rhythms)
|
|
Auto Accompaniment
|
Modes: CASIO Chord, Fingered 1, Fingered 2 (6th off), Fingered 3 (on bass), Full Range Chord
|
|
Controllers: Start/Stop, Intro, Normal/Fill-in, Variation/Fill-in, Synchro/Ending
|
|
Built-in Songs
|
5 (demo tunes)
|
|
Metronome
|
Beats: 0, 2, 3, 4, 5, 6 (Tempo range: quarter note = 30 to 255)
|
|
Recorder
|
Song sequencer: 16 multi tracks + 1 System Track, 5 songs, approximately 12,000 total notes (real-time recording, step recording, song edit, track edit,event edit)
|
|
Other Functions
|
Mixer: 32 channels
|
|
Rhythm editor (10 user rhythms)
|
|
Tone editor (10 user tones)
|
|
Registrations: 32 setups (4 sets x 8 banks)
|
|
Music preset: 305 preset with chord progression, chord edit ( 50 user presets)
|
|
One-touch preset: 210 sets
|
|
Arpeggiator: 150 types
|
|
Temperaments (scales): Preset scale (Equal temperament + 16 types)/scale fine tune
|
|
Octave shift: ±2 octaves
|
|
Rhythm/song controller
|
|
Pitch bend wheel : 0 to 24 semitones
|
|
Large Dial
|
|
Key Transpose
|
±1 (-12 to +12 semitones)
|
|
Tuning Control
|
A4 = 415.5 - 440.0 - 465.9 Hz
|
|
Pedals
|
Standard jack (sustain, soft, sostenuto, start/stop)
|
|
Display Screen
|
LCD with backlight
|
|
SD Memory Card Slot
|
Supported memory cards: Up to 32GB SD memory cards or SDHC memory cards
|
|
Functions: SMF playback (up to 320KB per file), file save/load/delete, card format
|
|
Save/load: Registrations, user rhythms, user tones, user DSPs, user music presets, song sequencer songs
|
|
MIDI
|
GM Compatibility: Level1
|
|
Terminals: USB
|
|
Speakers
|
12cm x 2 + 3cm x 2, bass-reflex system
|
|
Amp Output
|
6W＋6W
|
|
Input/Output Terminals
|
Audio in
|
|
Line output (L/MONO, R)
|
|
Headphones (standard stereo jack)
|
|
Sustain/assignable
|
|
USB: type B
|
|
External power (12V DC)
|
|
* USB cable (A-B type) required to use USB terminal for computer connection.
|
|
Power Requirements
|
Batteries: D-sizex6/AC adaptor: AD-A12150LW
|
|
Dimensions (W x D x H)
|
948 x 384 x 122mm
|
|
* Excluding music stand, and other projections
|
|
Weight
|
5.7kg (Excluding batteries)
|
|
Included Accessories
|
Music stand, AC adaptor (Not Included)
|
